CCM Z Series Linear Guide Actuators Belt Driven
Z45-20 linear guide rails belt driven
The Z45-20 With Motor On Carriage is perfect for applications like pick-and-place systems, small robotic arms, and automated testing stations. With a 20 kg load capacity, 1.5 m/s speed, 0.05 mm straightness, and 3 N·m torque, it ensures precise and smooth motion. The customizable length (up to 6 meters) and straightness make it ideal for tasks requiring high accuracy and moderate load handling, such as light-duty material handling, inspection systems, and lightweight automation processes.
Z50-30 Linear guide rail belt driven
The Z50-30 With Motor On Carriage is well-suited for applications like robotic arms, pick-and-place systems, and material handling. With a 30 kg load capacity, 2 m/s speed, 0.05 mm straightness, and 6.5 N·m torque, it provides smooth, reliable motion. The customizable length (up to 6 meters) and high precision make it ideal for handling medium-duty loads with accuracy and speed, making it perfect for medium-scale automation tasks, such as assembly lines and automated testing stations.
Z60-40 Linear guide rails belt driven
The Z60-40 With Motor On Carriage is ideal for medium to heavy-duty applications such as robotic arms, pick-and-place systems, and conveyor systems. With a 40 kg load capacity, 2 m/s speed, 0.05 mm straightness, and 8.5 N·m torque, it ensures precise and smooth motion for heavier loads. The customizable length (up to 6 meters) makes it perfect for applications that require high accuracy, speed, and reliability in tasks like material handling, automated testing, and medium-duty assembly lines.
Z80-50 Linear guide rails belt driven
The Z80-50 With Motor On Carriage is designed for heavy-duty applications such as large robotic arms, pick-and-place systems, and industrial conveyors. With a 50 kg load capacity, 2 m/s speed, 0.05 mm straightness, and 13.5 N·m torque, it provides high precision and stability for demanding tasks. The customizable length (up to 6 meters) allows for versatile use in automation systems requiring robust performance, speed, and accuracy, making it ideal for large-scale material handling, packaging, and industrial automation processes.
